Spirited weekend track drives do not have to sacrifice daily driving comfort or performance. Designed for the performance enthusiast in mind, the RS-R Sports-I coilover system provides a comfortable ride for everyday use, yet is sufficient enough for those effervescent track days.

Product Details

Part Number: XBIT532M

Compatibility: 2015-2017 Lexus NX200T AWD/FWD

Chassis code: AGZ10 & AGZ15

Preset Approximate Height: FWD

Front: -45mm (-1.8inch) Rear: -45mm (-1.8inch)

Maximum Adjustment Range: FWD

Front: -20mm to -125mm (-0.8inch to -5.0inch) Rear: -25mm to -80mm (-1.0inch to -3.1inch)

Recommended Adjustment Range: FWD

Front: -30mm to -70mm (-1.2inch to -2.8inch) Rear: -25mm to -80mm (-1.0inch to -3.1inch)

Preset Approximate Height: AWD

Front: -45mm (-1.8inch) Rear: -45mm (-1.8inch)

Maximum Adjustment Range: AWD

Front: -20mm to -125mm (-0.8inch to -5.0inch) Rear: -30mm to -80mm (-1.2inch to -3.1inch)

Recommended Adjustment Range: AWD

Front: -30mm to -70mm (-1.2inch to -2.8inch) Rear: -30mm to -80mm (-1.2inch to -3.1inch)

Spring Rate: Both

Front: 6.00kg/mm Rear: 6.30kg/mm

Additional Information

Dampers are 36 way adjustable in the front and the rear Warranty: 1 Year / 12,000 miles from the day of purchase
